GASOLINE ENGINE
 |
ĦĦĦĦĦĦĦĦMAIN SPECIFICATION
| Model | JF168
|
JF200
|
JF240
|
JF270
|
JF340
|
JF390
|
JF420
|
| Engine Type | 4-stroke, 25º inlined, single cylinder with air-cooled
|
||||||
| Bore x Stroke (mm) | 68x45
|
68x54
|
73x58
|
77x58
|
82x64
|
88x64
|
90x66
|
| Displacement (ml) | 163
|
196
|
242
|
270
|
337
|
389
|
420
|
| Compression Ratio | 8.5:1
|
||||||
| Max. Output (HP/rpm) | 5.5/3600
|
6.5/3600
|
8.0/3600
|
9.0/3600
|
11.0/3600
|
13.0/3600
|
15.0/3600
|
| Max. Torque (N.m/rpm) | 10.8/2500
|
13/2500
|
16.7/2500
|
19/2500
|
23.5/2500
|
26.4/2500
|
28.0/2500
|
| Ignition System | Non-contact Transistorized ignition(T.C.I.)
|
||||||
| Starting System | Recoil and hand-operated/Electric start
|
||||||
| Air Cleaner | Semi-dry, oil bath, dual, double silent and cyclone type
|
||||||
| Fuel Tank Capacity (liter) | 3.6
|
6 |
6.5 |
||||
| Fuel Consumption (g/HP-hour) | 270
|
260 |
260 |
||||
| Oil Capacity (liter/gal) | 0.6
|
1.1 |
1.1 |
||||
| Dimensions (LxWxH)(mm) | 387x330x360
|
460x380x410 |
530x405x480 |
||||
| Net Weight (kg) | 15
|
16 |
25 |
31 |
|||
| 20/40FT unit |
575/1254 |
354/744 |
354/786
|
||||
